The Dell WD19 is a modular USB-C docking station that connects a laptop to multiple displays, peripherals, and wired networks through a single USB-C cable.
Key Specifications & Features
• Video Ports:
• 2 x DisplayPort 1.4 (DisplayPort++)
• 1 x HDMI 2.0
• 1 x USB-C Multifunction DisplayPort (shares hardware with the HDMI port)
• USB Ports:
• 1 x Front USB 3.1 Gen 1 with PowerShare
• 1 x Front USB 3.1 Gen 1/Gen 2 Type-C
• 2 x Rear USB 3.1 Gen 1 Type-A
• 1 x Rear USB 3.1 Gen 1/Gen 2 Type-C with DisplayPort 1.4
• Audio Ports:
• 1 x Front 3.5mm headset combo connector
• 1 x Rear 3.5mm line-out port
• Network Port:
• 1 x Gigabit Ethernet (RJ-45) with Wake-on-LAN and MAC Address Pass-Through support (on select systems)
• Power Delivery:
• Up to 90W–130W power delivery for compatible Dell laptops (depending on the AC adapter wattage, typically a 130W or 180W power brick)
• Up to 90W power delivery for non-Dell USB-C systems via USB Power Delivery (PD) 3.0
• Physical Dimensions & Weight:
• Size: 205 mm x 90 mm x 29 mm (8.1 in x 3.5 in x 1.1 in)
• Weight: 590 g (1.30 lbs)
• Attached Cable: 1-meter USB-C cable
• Other Features:
• Integrated top power/sleep/wake button (mirrors compatible Dell system power buttons)
• Noble Wedge and Kensington security lock slots
• Modular design allowing future upgrades to Thunderbolt (WD19TB) or dual-USB-C (WD19DC) modules if needed.
